OUTDOOR WALL PACK ADJUSTABLE LIGHT SENSOR IP65 10000LM 80W 4000K 120 BEAM BLACK INTEGRAL
Part Number:
ILWPC003
Integral Compact Tough Wall Pack Lights are ideal for perimeter lighting as well as pedestrian and vehicle access areas in commercial and industrial environments. The IP65 weatherproof and IK08 impact-resistant cast aluminium body makes it perfectly suitable for outdoor installation.
This model features a 90 degree adjustable head to shine light where you need it, as well as a light sensor, so the unit automatically switches on at dusk and off at dawn, increasing efficiency.
- Product Feature 1:
- Light sensor for increased efficiency
- Product Feature 2:
- 0-90 degree adjustable head
- Product Feature 3:
- Stylish and contemporary design
- Product Feature 4:
- Hard-wearing and weatherproof
- Product Feature 5:
- Cast-aluminium body
- Availability:
-
13
Call us on 0208 451 8700 to check the next availability
Suggested products
Details
| Barcode | 5055788241829 |
|---|---|
| Quick Order Code | '079049 |
| Product Type | Wall Packs |
| Category | Luminaires |
| Range Name | Compact Tough |
| Finish | Dark Brown |
| Product Body Finish | Dark Brown |
| Features | Dusk-to-Dawn Sensor |
| Market Segment | Outdoor |
| Placement / Application | Outdoor |
| Warranty (Years) | 3 |
Physical Data
| Bulb or Luminaire Shape | Rectangle |
|---|---|
| Product Length (mm) | 285 |
| Product Width (mm) | 265 |
| Product Depth (mm) | 119 |
| Product Weight (g) | 4290 |
| Material | ADC12 Aluminium |
| Construction | Aluminium heat-sink, PC injection moulded driver case |
| Luminaire Fixing | Wall |
| Emergency Option | No |
| Linkable | No |
| Optic | Polycarbonate diffuser |
| Mounting Type | Rear Cable Entry |
Light Data
| Luminous Flux in Lumens (lm) | 10000 |
|---|---|
| Luminous efficacy (lm/W) | 123 |
| Colour Temperature Name | Cool White |
| Beam Angle | 120 |
| Colour Rendering Index (CRI) | 80 |
| Frequency Range (Hz) | 50/60 |
| Lifetime (hours) | 50000 |
| Switching Cycles | 100000 |
| Useful Lumens (lm) | 9840 |
| Light Source | Non-replaceable |
Electrical Data
| Power (W) | 80 |
|---|---|
| Power Consumption (W) | 80 |
| Power Factor | 0.95 |
| Voltage Range (v) | 100-277 |
| Input Voltage (V) | 220-240 |
| Dimming | Non-Dimmable |
| Electric Current | AC |
Environmental
| IP Rating (Ingress Protection) | IP65 |
|---|---|
| Lowest Operating Temperature (°C) | 0 |
| Maximum Operating Temperature (°C) | 45 |
| EN | EN-60598 |
| LVD Certified | Yes |
| CE RoHS | Yes |
| Hg 0% (Mercury Free) | Yes |
| IK Rating (Impact Protection) | IK08 |
| EU Luminaire | L |
Packaging
| Barcode | 5055788241829 |
|---|---|
| Package Weight (g) | 4690 |
| Package Length (mm) | 335 |
| Package Width (mm) | 315 |
| Package Depth (mm) | 170 |
