Product Specification Sheet

CANDLE BULB B15 470LM 4.2W 2700K NON-DIMM 240 BEAM FROSTED INTEGRAL

ILCANDB15NC014

This 4.2 W retro-fit Integral LED Candle (frosted finish, small bayonet, white base]) delivers a warm light and brightness, similar to a 40W filament bulb. It features high output LEDs and an anti-glare refractor. Ideal for living rooms, dining rooms, bedrooms and hotels, in classic or modern wall or floor/table lamp fittings and chandeliers.

Details

Barcode:
5055788210214
Quick Order Code:
408888
Category:
Lamps
Range Name:
Everyday
Product Type:
Candle
Warranty (Years):
2
CE RoHS:
Yes

Physical Data

Product Length (mm):
101
Product Width (mm):
35
Product Weight (g):
22
Material:
Plastic, Aluminium, Polycarbonate, Nickel plated brass
Base Term:
Small Bayonet cap
Bulb Base:
B15
Construction:
Aluminium and Plastic heat-sink, Injection moulded diffuser
Globe Finish:
Frosted
Globe Type:
Candle
Bulb Fixing:
Pendant, Chandelier, Wall
Bulb or Luminaire Shape:
Oval

Electrical Data

Power (W):
4.2
Power Consumption (W) :
4.2
Power Factor:
0.5
Voltage Range (v):
220-240
Wattage equivalent (W):
40
Amperage (mA):
36
Dimming:
Non-Dimmable
Driver IC Manufacturer:
Silergy
Driver Included:
Yes
Electric Current:
AC
EN:
EN-62560
LVD Certified:
Yes

Light Data

Luminous Flux in Lumens (lm):
470
Luminous efficacy (lm/W):
112
Correlated Colour Temperature (CCT) (K):
2700
Colour Temperature:
2700K - Warm
Colour Temperature Name:
Warm
Beam Angle:
240
Colour Rendering Index (CRI):
80
Frequency Range (Hz):
50/60, 50
Instant on (Less than 1 second):
Yes
LED Type:
Surface mounted device (SMD)
Lifetime (hours):
15000
Switching Cycles:
50000

Environment

EN:
EN-62560
LVD Certified:
Yes
CE RoHS:
Yes
Previous Energy Rating:
A+
New Energy Rating:
F, E
Hg 0% (Mercury Free):
Yes
IP Rating (Ingress Protection):
IP20
Lowest Operating Temperature (°C):
-20
Maximum Operating Temperature (°C):
40

Packaging

Package Weight (g):
69, 32
Package Length (mm):
110, 125
Package Width (mm):
50, 48
Package Depth (mm):
48, 50
Qty per euro pallet:
1600, 3840
