G9 BULB 300LM 2.7W 2700K DIMMABLE 300 BEAM INTEGRAL
ILG9DC011
This Integral LED G9 lamp offers a high lumen output in 2700K. At 3W this smooth dimming capsule lamp is highly efficient compared to the halogen lamps they are designed to replace. Ideal for pendant fittings and accent lighting in domestic, hospitality and retail applications.
Details
- Barcode:
- 5055788260165
- Quick Order Code:
- 638244
- Category:
- Lamps
- Range Name:
- G9
- Product Type:
- G9
- Market Segment:
- Commercial indoor, Residential indoor
- Warranty (Years):
- 2
Physical Data
- Product Length (mm):
- 52
- Product Width (mm):
- 16
- Product Weight (g):
- 8.5
- Base Term:
- G9
- Bulb Base:
- G9
- Construction:
- Plastic heat-sink, Injection moulded diffuser
- Globe Finish:
- Clear
- Bulb Fixing:
- Pendant, Wall, Desktop
- Bulb or Luminaire Shape:
- Cylindrical
- Placement / Application:
- Indoor, General Lighting
Electrical Data
- Power (W):
- 2.7
- Power Consumption (W) :
- 2.7
- Power Factor:
- 0.4
- Voltage Range (v):
- 220-240
- Wattage equivalent (W):
- 28
- Amperage (mA):
- 16
- Dimming:
- Mains dim
- Driver Included:
- Yes
- Electric Current:
- AC
- EN:
- EN-62560
- LVD Certified:
- Yes
Light Data
- Luminous Flux in Lumens (lm):
- 300
- Luminous efficacy (lm/W):
- 111
- Correlated Colour Temperature (CCT) (K):
- 2700
- Colour Temperature:
- 2700K - Warm
- Colour Temperature Name:
- Warm
- Beam Angle:
- 300
- Colour Rendering Index (CRI):
- 80
- Frequency Range (Hz):
- 50/60
- Instant on (Less than 1 second):
- Yes
- LED Type:
- SMD
- Lifetime (hours):
- 15000
- Switching Cycles:
- 50000
Environment
- EN:
- EN-62560
- LVD Certified:
- Yes
- CE RoHS:
- Yes
- New Energy Rating:
- E
- Hg 0% (Mercury Free):
- Yes
- IP Rating (Ingress Protection):
- IP20
- Lowest Operating Temperature (°C):
- -20
- Maximum Operating Temperature (°C):
- 45
Packaging
- Barcode:
- 5055788260165
- Single box qty:
- 1
- Package Weight (g):
- 15
- Package Length (mm):
- 20
- Package Width (mm):
- 20
- Package Depth (mm):
- 54
- Inner Carton Barcode:
- 05055788260271
- Qty per Inner Carton :
- 20
- Inner Carton Length (mm):
- 11
- Inner Carton Width (mm):
- 90
- Inner Carton Depth (mm):
- 63
- Outer Carton Barcode:
- 05055788260387
- Qty per Outer Carton:
- 120
- Outer Carton Length (mm):
- 291
- Outer Carton Width (mm):
- 126
- Outer Carton Depth (mm):
- 151
- Qty per euro pallet:
- 36000
