GLS BULB B22 470LM 4W 2700K DIMMABLE 240 BEAM FROSTED INTEGRAL
ILGLSB22DC020
This 4W retro-fit Integral LED Classic Globe (GLS) (large bayonet base) delivers a dimmable, warm light and brightness, similar to a 40W filament bulb. It features high output LEDs and an anti-glare refractor. Ideal for low level light areas such as hallways, bedrooms, cupboards or where light is always on.
Details
- Barcode:
- 5055788202134
- Quick Order Code:
- 603979
- Category:
- Lamps
- Range Name:
- Legacy
- Product Type:
- GLS
- Market Segment:
- Commercial indoor, Residential indoor
- Warranty (Years):
- 2
- CE RoHS:
- Yes
Physical Data
- Product Length (mm):
- 105
- Product Width (mm):
- 60
- Product Weight (g):
- 32
- Material:
- Plastic, Polycarbonate, Nickel plated brass
- Base Term:
- Bayonet cap
- Bulb Base:
- B22
- Construction:
- Plastic heat-sink, Injection moulded diffuser
- Globe Finish:
- Frosted
- Globe Type:
- GLS
- Bulb Fixing:
- Pendant, Wall
- Bulb or Luminaire Shape:
- Round
- Placement / Application:
- Indoor, General Lighting
Electrical Data
- Power (W):
- 4
- Power Consumption (W) :
- 4
- Power Factor:
- 0.7
- Voltage Range (v):
- 220-240
- Wattage equivalent (W):
- 40
- Amperage (mA):
- 25
- Dimming:
- Dimmable, Dimmable with compatible dimmers
- Driver IC Manufacturer:
- IWATT
- Driver Included:
- Yes
- Electric Current:
- AC
- EN:
- EN-62560
- LVD Certified:
- Yes
Light Data
- Luminous Flux in Lumens (lm):
- 470
- Luminous efficacy (lm/W):
- 117
- Correlated Colour Temperature (CCT) (K):
- 2700
- Colour Temperature:
- 2700K - Warm
- Colour Temperature Name:
- Warm
- Beam Angle:
- 240
- Colour Rendering Index (CRI):
- 80
- Compatible Dimmers:
- Varilight JQP401W
- Frequency Range (Hz):
- 50
- Instant on (Less than 1 second):
- Yes
- LED Type:
- Surface mounted device (SMD)
- Lifetime (hours):
- 15000
- Switching Cycles:
- 50000
Environment
- EN:
- EN-62560
- LVD Certified:
- Yes
- CE RoHS:
- Yes
- Previous Energy Rating:
- A+
- New Energy Rating:
- F, E
- Hg 0% (Mercury Free):
- Yes
- IP Rating (Ingress Protection):
- IP20
- Lowest Operating Temperature (°C):
- -20
- Maximum Operating Temperature (°C):
- 40
Packaging
- Package Weight (g):
- 56
- Package Length (mm):
- 65
- Package Width (mm):
- 65
- Package Depth (mm):
- 120
- Qty per euro pallet:
- 1200, 1440
