COMPACT ECO LINEAR 120W 18600LM 4000K 155LM/W 120 BEAM NON-DIMM INTEGRAL
Part Number:
ILHBL090
The Compact Eco Linear beam light boasts 18600LM illumination with an efficacy of 155LM/W, ensuring you won’t need to sacrifice brightness for energy savings. Its cool white light colour evokes an energising, clean space, while the IP65 and IK08 ratings protect it from dust, light water sprays, and impacts-perfect for commercial and industrial indoor settings. 3 years warranty for your peace of mind.
- Product Feature 1:
- 18600lm
- Product Feature 2:
- Cool White
- Product Feature 3:
- 155lm/W
- Product Feature 4:
- Class I
- Product Feature 5:
- 3 Year Warranty
- Availability:
-
100+
Call us on 0208 451 8700 to check the next availability
Details
| Barcode | 5055788261018 |
|---|---|
| Quick Order Code | 245737 |
| Category | Luminaires |
| Range Name | Compact Eco |
| Type | Linear |
| Market Segment | Commercial indoor, Industrial indoor |
| Warranty (Years) | 3 |
Physical Data
| Emergency Option | No |
|---|---|
| Product Length (mm) | 1220 |
| Product Weight (g) | 4000 |
| Optic | Polycarbonate |
| Material | Aluminium, Polycarbonate |
| Construction | Aluminium heat-sink and driver case |
| Bulb or Luminaire Shape | Linear |
| Luminaire Fixing | Surface or Suspended |
| Mounting Type | Surface or Suspended |
| Placement / Application | Indoor, Commercial and Industrial |
| Control Gear | Non-replaceable |
Light Data
| Luminous Flux in Lumens (lm) | 18600 |
|---|---|
| Luminous efficacy (lm/W) | 155 |
| Correlated Colour Temperature (CCT) (K) | 4000 |
| Colour Temperature Name | Cool White |
| Beam Angle | 120 |
| Colour Rendering Index (CRI) | 80 |
| Frequency Range (Hz) | 50/60 |
| Instant on (Less than 1 second) | Yes |
| LED Size (mm) | 2835 |
| LED Type | Surface mounted device (SMD) |
| Lifetime (hours) | 50000 |
| Switching Cycles | 15000 |
| Light Source | Non-replaceable |
Electrical Data
| Power Consumption (W) | 120 |
|---|---|
| Power Factor | 0.9 |
| Voltage Range (v) | 220-240 |
| Wattage equivalent (W) | 186 |
| Dimming | Non-Dimmable |
| Driver Included | Yes |
| Electric Current | AC |
| EN | EN-60598, EN61000, EN61547, EN55015, IEC62321 |
| LVD Certified | Yes |
Environmental
| EN | EN-60598, EN61000, EN61547, EN55015, IEC62321 |
|---|---|
| LVD Certified | Yes |
| CE RoHS | Yes |
| New Energy Rating | C |
| EU Luminaire | L |
| Hg 0% (Mercury Free) | Yes |
| IK Rating (Impact Protection) | IK08 |
| IP Rating (Ingress Protection) | IP65 |
| Lowest Operating Temperature (°C) | -10 |
| Maximum Operating Temperature (°C) | 40 |
Packaging
| Barcode | 5055788261018 |
|---|---|
| Single box qty | 1 |
| Package Weight (g) | 4400 |
| Package Length (mm) | 1270 |
| Package Width (mm) | 130 |
| Package Depth (mm) | 66 |
| Outer Carton Barcode | 5055788261018 |
| Qty per Outer Carton | 4 |
| Outer Carton Length (mm) | 1265 |
| Outer Carton Width (mm) | 245 |
| Outer Carton Depth (mm) | 130 |
Safety Guide
