GU10 BULB 5 PACK 600LM 5.7W 2700K DIMMABLE 36 BEAM INTEGRAL
Part Number:
ILGU10DC117-5
The cleverly engineered surface mounted LEDs of the Integral LED GU10 range give them an attractive look that is very similar to traditional halogen lamps.
These dimmable GU10 lamps will retrofit easily into existing fittings and provide significant energy savings and longer lifetime than the halogen lamps they are designed to replace.
- Product Feature 1:
- Warm Light
- Product Feature 2:
- 540 Useful Lumens (600 Nominal)
- Product Feature 3:
- Dimmable with compatible dimmers
- Availability:
-
0
More stock due in on 17/12/2025
Details
| Barcode | 5055788323860 |
|---|---|
| Quick Order Code | 594634 |
| Category | Lamps |
| Range Name | 240V GU10 Base |
| Product Type | GU10 |
| Product Body Finish | Matt white |
| Market Segment | Commercial indoor, Residential indoor |
| Finish | Clear |
| Warranty (Years) | 2 |
Physical Data
| Product Length (mm) | 54 |
|---|---|
| Product Width (mm) | 50 |
| Product Weight (g) | 27 |
| Optic | Designed to give a Classic Look |
| Material | Plastic and Aluminium heat-sink, Injection moulded diffuser |
| Base Term | GU10 |
| Bulb Base | GU10 |
| Construction | Plastic White and "Classic look" diffuser lens |
| Bulb or Luminaire Shape | Round |
| Placement / Application | Indoor, General Lighting |
| Spot Type | SMD |
Light Data
| Energy Efficiency Label (Image) | ILGU10DC117-5_EU_label |
|---|---|
| Luminous Flux in Lumens (lm) | 600 |
| Luminous efficacy (lm/W) | 95 |
| Peak Intensity (Cd) | 1050 |
| Correlated Colour Temperature (CCT) (K) | 2700 |
| Colour Temperature | 2700K - Warm |
| Colour Temperature Name | Warm |
| Beam Angle | 36 |
| Colour Rendering Index (CRI) | 80 |
| Compatible Dimmers | Varilight JQP401W |
| Frequency Range (Hz) | 50/60 |
| Instant on (Less than 1 second) | Yes |
| LED Type | Surface mounted device (SMD) |
| Lifetime (hours) | 25000 |
| Switching Cycles | 50000 |
| Useful Lumens (lm) | 540 |
Electrical Data
| Power (W) | 5.7 |
|---|---|
| Power Consumption (W) | 5.7 |
| Power Factor | 0.5 |
| Voltage Range (v) | 220-240 |
| Wattage equivalent (W) | 75 |
| Amperage (mA) | 33 |
| Dimming | Mains dim |
| Driver Included | Yes |
| Electric Current | AC |
| True Wattage Eq (W) | 75 |
| EN | EN-62560 |
| LVD Certified | Yes |
Environmental
| EN | EN-62560 |
|---|---|
| LVD Certified | Yes |
| CE RoHS | Yes |
| New Energy Rating | E |
| Hg 0% (Mercury Free) | Yes |
| IP Rating (Ingress Protection) | IP20 |
| Lowest Operating Temperature (°C) | -20 |
| Maximum Operating Temperature (°C) | 40 |
Packaging
| Barcode | 5055788323860 |
|---|---|
| Single box qty | 5 |
| Package Weight (g) | 115 |
| Package Length (mm) | 105 |
| Package Width (mm) | 105 |
| Package Depth (mm) | 60 |
| Outer Carton Barcode | 05055788323860 |
| Qty per Outer Carton | 20 |
| Outer Carton Length (mm) | 550 |
| Outer Carton Width (mm) | 230 |
| Outer Carton Depth (mm) | 140 |
Safety Guide
ILGU10DC117-5
