PERFORMANCE RECESS PL 230MM BEZEL 195-210MM CUTOUT 120LM/W 26W/35W 3120/4200LM 3000/4000/5700K CCT ALUMINIUM IP44 COMMERICAL DOWNLIGHT NON-DIM
Part Number:
ILDL230PR004
- Product Feature 1:
- High Efficacy - 120 lm/W
- Product Feature 2:
- Shallow recessed design
- Product Feature 3:
- Aluminimum body with PC diffuser
- Product Feature 4:
- CCT Switchable
- Product Feature 5:
- 4 sizes - cutout options from 90mm to 210mm
- Availability:
-
0
More stock due in on 12/09/2025
Suggested products
Details
Barcode | 5055788323617 |
---|---|
Quick Order Code | 978731 |
Category | Downlights |
Range Name | Performance Recess |
Product Type | Downlight |
Product Body Finish | Matt white |
Market Segment | Commercial indoor, Residential indoor |
Features | CCT Switchable |
Fixed/Tiltable | Fixed |
Warranty (Years) | 5 |
Physical Data
Emergency Option | No |
---|---|
Product Length (mm) | 232 |
Product Depth (mm) | 85 |
Product Width (mm) | 232 |
Product Weight (g) | 400 |
Diameter (mm) | 232 |
Optic | PS Diffuser |
Material | Aluminium, Plastic |
Overall diameter (mm) | 232 |
Construction | Aluminium body, Polycarbonate diffuser |
Cut Out Diameter (mm) | 195-210 |
Bulb or Luminaire Shape | Round |
Luminaire Fixing | Recess mounted |
Placement / Application | Indoor, General Lighting |
Spot Type | SMD |
Light Data
Luminous Flux in Lumens (lm) | 3120, 4200 |
---|---|
Luminous efficacy (lm/W) | 120 |
Correlated Colour Temperature (CCT) (K) | 5700, 3000, 4000 |
Colour Temperature | 3000/4000/5700 - Warm White/Cool White/Daylight |
Colour Temperature Name | CCT Switchable |
Beam Angle | 110 |
Colour Rendering Index (CRI) | 80 |
Frequency Range (Hz) | 50/60 |
Instant on (Less than 1 second) | Yes |
Integrated Light Source | Yes |
LED Type | Surface mounted device (SMD) |
Lifetime (hours) | 50000 |
Switching Cycles | 50000 |
Useful Lumens (lm) | 3120, 4200 |
Electrical Data
Power Consumption (W) | 35, 26 |
---|---|
Power Factor | 0.5 |
Voltage Range (v) | 220-240 |
Amperage (mA) | 900 |
Dimming | Non-Dimmable |
Driver Included | Yes |
Electric Current | AC |
Insulation Guard | No |
EN | EN-60598 |
LVD Certified | Yes |
Environmental
EN | EN-60598 |
---|---|
LVD Certified | Yes |
CE RoHS | Yes |
Hg 0% (Mercury Free) | Yes |
IP Rating (Back/Recessed side) | IP20 |
IP Rating (Ingress Protection) | IP44 |
Lowest Operating Temperature (°C) | -10 |
Maximum Operating Temperature (°C) | 40 |
Packaging
Barcode | 5055788323617 |
---|---|
Single box qty | 1 |
Package Weight (g) | 0.515 |
Package Length (mm) | 247 |
Package Width (mm) | 247 |
Package Depth (mm) | 95 |
Outer Carton Barcode | 05055788323655 |
Qty per Outer Carton | 12 |
Outer Carton Length (mm) | 515 |
Outer Carton Width (mm) | 515 |
Outer Carton Depth (mm) | 305 |
