DIGITAL PIXEL STRIP IP20 5M RGB 12V 14.4W/M 60LED/M 10MM WIDTH 115 BEAM BAG PACK INTEGRAL

Part Number:

ILSTRGBA073E

Experience an explosion of colour with our Digital Pixel RGB Strip. Control 1 digital IC chip per 3 LEDs to create a colour changing and cascading LED effect in your space. Program the Digital Pixel RGB strip to perform flash effects, single or multicolour chase effect, light curtains and gradual fades. Don't allow technology to limit your creativity, take the next step towards the future of LED strip lighting.

Product Feature 1:
Colour changing and cascade effect LED strip
Product Feature 2:
1 Digital IC chip per 3 LEDs
Product Feature 3:
12V Constant Voltage
Product Feature 4:
60 LEDs per metre
Product Feature 5:
14.4W per metre
Availability:
100+

Call us on 0208 451 8700 to check the next availability

Suggested products

Quick Order Code 592411
Barcode 5055788235149
Category Strips
Range Name Digital Pixel Strip
Product Type Colour strip
Market Segment Indoor commercial, Industrial, residential
Features Digital Pixel RGB
Warranty (Years) 3
Product Width (mm) 10
Product Weight (g) 130
Material PCB
Construction LED surface mounted on to strip
Strip Cut Points (mm) 50
Max Run Length (m) 5
Placement / Application Decorative Indoor, General Lighting
Strip length (M) 5
Strip Width (mm) 10
Colour Temperature Name RGB
Beam Angle 120
Colour Rendering Index (CRI) 80
Colour Type Digital Pixel
LED Size (mm) 5050
LED Type Surface mounted device (SMD)
LEDs per meter 60
Lifetime (hours) 25000
Power Consumption per meter (W/m) 14.4
Voltage (V) 12
Voltage Range (v) 12
Watts per metre 10.1w - 20w
Dimming Dimmable
Electric Current DC
EN IEC 62031
LVD Certified Yes
EN IEC 62031
LVD Certified Yes
CE RoHS Yes
Hg 0% (Mercury Free) Yes
IP Rating (Ingress Protection) IP20
Lowest Operating Temperature (°C) -25
Maximum Operating Temperature (°C) 60
Package Weight (g) 140
Package Length (mm) 210
Package Width (mm) 250
Package Depth (mm) 10

Product Specification Sheet

Safety Guides

Installation Guides

Wiring Diagrams
