VAPOURLITE 4FT IP65 IK08 20W/38W 4000K/5000K/6500K 120 BEAM ANGLE 130LM/W NON_DIMM

Part Number:

ILBTD202

Product Feature 1:
Power & CCT Switchable
Product Feature 2:
50000hrs
Product Feature 3:
IP65 body protects against dust and moisture ingress
Product Feature 4:
130lm/W
Product Feature 5:
5 Year Warranty
Product Feature 6:
IP65
Product Feature 7:
IK08
Availability:
0

More stock due in on 07/06/2024

Quick Order Code '023705
Barcode 5055788267393
Category Luminaires
Range Name Vapourlite
Type Single / Twin
Product Body Finish Grey
Market Segment Commercial indoor and outdoor, Industrial indoor and outdoor
Features Power & CCT Switchable
Warranty (Years) 5
Emergency Option No
Size (in ft) 4ft
Linkable Yes
Product Length (mm) 1205
Product Depth (mm) 71
Product Width (mm) 82
Product Weight (g) 1304
Optic Polycarbonate diffuser
Material Polycarbonate
Construction Injection moulding
Bulb or Luminaire Shape Linear
Luminaire Fixing Ceiling mounted
Placement / Application Indoor, Commercial and Industrial
Energy Efficiency Label (Image) ILBTD202_EU_label
Luminous Flux in Lumens (lm) 2600 to 4940
Correlated Colour Temperature (CCT) (K) 4000/5000/6500
Colour Temperature 4000/5000/6500
Colour Temperature Name CCT Switchable
Beam Angle 120
Colour Rendering Index (CRI) 80
Frequency Range (Hz) 50/60
Instant on (Less than 1 second) Yes
LED Size (mm) 2835
LED Type Surface mounted device (SMD)
Lifetime (hours) 50000
Switching Cycles 25000
Power Consumption (W) 20 & 38
Power Factor 0.9
Voltage Range (v) 200-240
Input Voltage (V) 200-240
Dimming Non-Dimmable
Driver Included Yes
Electric Current AC
EN EN-60598
LVD Certified Yes
EN EN-60598
LVD Certified Yes
CE RoHS Yes
New Energy Rating E
EU Luminaire L
Hg 0% (Mercury Free) Yes
IK Rating (Impact Protection) IK08
IP Rating (Ingress Protection) 65
Lowest Operating Temperature (°C) -20
Maximum Operating Temperature (°C) 40
Package Weight (g) 1504
Package Length (mm) 1210
Package Width (mm) 86
Package Depth (mm) 76
