CONSTANT VOLTAGE DRIVER 240W 48VDC IP65 NON-DIMM 90-305V INPUT
Part Number:
HLG-240H-48A
This non-dimmable 240W constant voltage LED driver operates 90-305VAC input range. The LED driver provides 48V constant voltage for applications such as 48V LED strip lighting.
- Product Feature 1:
- Input Voltage: 90-305VAC
- Product Feature 2:
- Output Power: 240W
- Product Feature 3:
- Output: 48VDC Constant Voltage
- Product Feature 4:
- Short Circuit / Over Load / Over Heat Protection
- Availability:
-
13
Call us on 0208 451 8700 to check the next availability
Details
| Quick Order Code | 933459 |
|---|---|
| Barcode | 5055788257844 |
| Category | Drivers |
| Range Name | Non-Dimmable |
| Product Type | Constant Voltage |
| Market Segment | Commercial indoor |
| Warranty (Years) | 5 |
Physical Data
| Product Length (mm) | 244.2 |
|---|---|
| Product Depth (mm) | 38.8 |
| Product Width (mm) | 68 |
| Product Weight (g) | 1000 |
| Placement / Application | Indoor LED Lighting |
Light Data
| Frequency Range (Hz) | 50/60 |
|---|
Electrical Data
| Power Consumption (W) | 240 |
|---|---|
| Power Factor | 0.95 |
| Voltage (V) | 48 |
| Voltage Range (v) | 90-305 |
| Input Current (A) | 2 |
| Input Voltage (V) | 90-305VAC |
| Output Current (mA) | 5000 |
| Dimming | Non-Dimmable |
| Protection Function | Short Circuit Protection, Overload Protection, Overheat Protection |
| EN | EN61347-1, EN61347-2-13, EN55015, EN6100-3-3, EN6100-3-2, EN61547 |
| LVD Certified | Yes |
Environmental
| EN | EN61347-1, EN61347-2-13, EN55015, EN6100-3-3, EN6100-3-2, EN61547 |
|---|---|
| LVD Certified | Yes |
| CE RoHS | Yes |
| Hg 0% (Mercury Free) | Yes |
| IP Rating (Ingress Protection) | IP65 |
| Lowest Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 50 |
Packaging
| Package Weight (g) | 1300 |
|---|---|
| Package Length (mm) | 310 |
| Package Width (mm) | 95 |
| Package Depth (mm) | 45 |
