TOUGHSHELL CIRCULAR HIGH BAY 1PK IP44 15000LM 100W 4000K 120 BEAM 1-10V DIMMABLE EMERGENCY INTEGRAL

Part Number:

ILHBC142E

The Tough-Shell Circular High Bay is a rugged, attractive and highly efficient solution for lighting large indoor facilities such as warehouses, production facilities and indoor sports halls. Running at an efficacy of 130lm/W, this Tough-Shell provides up to 26,000lm and thanks to its skilfully engineered aluminium body it effectively dissipates heat while maintaining IK10 impact resistance.

This emergency model will provide 2600lm for 3 hours in the event of a power cut.

Product Feature 1:
120 degree beam angle
Product Feature 2:
150lm/W
Product Feature 3:
Cool White
Product Feature 4:
Dimmable
Product Feature 5:
5 Year Warranty
Product Feature 6:
Integrated Emergency function
Availability:
3

Call us on 0208 451 8700 to check the next availability

Suggested products

Barcode 5055788246169
Category Luminaires
Range Name Tough-Shell
Type Circular
Product Type Circular High Bay
Product Body Finish Matt Black
Market Segment Commercial indoor/outdoor, Industrial indoor/outdoor
Finish Matt Black
Features Emergency Function
Warranty (Years) 5
Emergency Option Integrated
Emergency Category High Bays
Product Length (mm) 139
Product Depth (mm) 139
Product Width (mm) 360
Product Weight (g) 6200
Diameter (mm) 360
Optic Polycarbonate diffuser
Material Aluminium, Polycarbonate
Construction Aluminium heat-sink, PC injection moulded driver case
Bulb or Luminaire Shape Round
Luminaire Fixing Suspended
Mounting Type Rear Cable Entry
Placement / Application Indoor, Outdoor, General Lighting
Typical Mounting Height 4M+
Energy Efficiency Label (Image) ILHBC142E_EU_label
Luminous Flux in Lumens (lm) 15000
Luminous efficacy (lm/W) 150
Correlated Colour Temperature (CCT) (K) 4000
Colour Temperature Name Cool White
Beam Angle 120
Colour Rendering Index (CRI) 73
Frequency Range (Hz) 50/60
Instant on (Less than 1 second) Yes
LED Type Surface mounted device (SMD)
Lifetime (hours) 50000
Switching Cycles 25000
Useful Lumens (lm) 15000
Power Consumption (w) 100
Power Factor 0.95
Voltage Range (v) 100-240
Input Voltage (V) 220-240
Dimming Dimmable
Driver Included Yes
Electric Current AC
Emergency Type Non-Maintained
EN EN-60598, EN61000, EN61547, EN55015, IEC62321
LVD Certified Yes
EN EN-60598, EN61000, EN61547, EN55015, IEC62321
LVD Certified Yes
CE RoHS Yes
EU Luminaire L
Hg 0% (Mercury Free) Yes
IK Rating (Impact Protection) IK08
IP Rating (Ingress Protection) IP40
Lowest Operating Temperature (°C) 0
Maximum Operating Temperature (°C) 45
Metal Halide Equivalent 150
Package Weight (g) 7800
Package Length (mm) 445
Package Width (mm) 225
Package Depth (mm) 445

Product Specification Sheet

Installation Guides
