GOLF BALL BULB B22 470LM 5W 2700K DIMMABLE 240 BEAM FROSTED INTEGRAL

Part Number:

ILGOLFB22DC045

This 6.3W retro-fit Integral LED Mini Globe (large bayonet base) delivers a warm light and brightness, similar to a 40W filament bulb. It features high output, multi Everlight LEDs and an anti-glare refractor. Ideal for living rooms, dining rooms and bedrooms, in classic or modern wall or floor/table lamp fittings.

Product Feature 1:
Warm Light
Product Feature 2:
470 Lumens
Product Feature 3:
Dimmable with compatible dimmers
Product Feature 4:
iWATT IC for exceptional dimming performance
Availability:
6

More stock due in on 22/09/2021

Barcode 5055788238140
Category Lamps
Range Name Everyday
Product Type Golf Ball
Market Segment Commercial indoor, Residential indoor
Warranty (Years) 3
Product Length (mm) 86
Product Width (mm) 45
Product Weight (g) 78
Material Plastic, Aluminium, Glass, Nickel plated brass
Base Term Bayonet cap
Bulb Base B22
Construction Plastic and Aluminium heat-sink, glass diffuser
Globe Finish Frosted
Globe Type Golf Ball
Bulb Fixing Pendant, Wall
Bulb or Luminaire Shape Round
Placement / Application Indoor, General Lighting
Energy Efficiency Label (Image) ILGOLFB22DC045_EU_label
Luminous Flux in Lumens (lm) 470
Luminous efficacy (lm/W) 75
Correlated Colour Temperature (CCT) (K) 2700
Colour Temperature 2700K - Warm
Colour Temperature Name Warm
Beam Angle 260
Colour Rendering Index (CRI) 80
Frequency Range (Hz) 50
Instant on (Less than 1 second) Yes
LED Type Surface mounted device (SMD)
Lifetime (hours) 25000
Switching Cycles 12500
Power (W) 6.3
Power Consumption (w) 6.3
Power Factor 0.5
Voltage Range (v) 220-240
Wattage equivalent (W) 40
Amperage (mA) 58
Dimming Dimmable
Driver IC Manufacturer IWATT
Driver Included Yes
Electric Current AC
EN EN-62560
LVD Certified Yes
EN EN-62560
LVD Certified Yes
CE RoHS Yes
Energy Rating A+
Hg 0% (Mercury Free) Yes
IP Rating (Ingress Protection) IP20
Lowest Operating Temperature (°C) -20
Maximum Operating Temperature (°C) 40
Package Weight (g) 106
Package Length (mm) 100
Package Width (mm) 56
Package Depth (mm) 56

Product Specification Sheet
