CLASSIC FILAMENT GLS BULB B22 806LM 5.9W 5000K NON-DIMM 330 BEAM FROSTED INTEGRAL
Part Number:
ILGLSB22NF091
THIS ITEM IS NOW UPGRADED OR DISCONTINUED. CONTACT US TO FIND A REPLACEMENT PRODUCT.
The Classic Full Glass Frosted lamp utilises Filament LED technology to create a decorative look and wide beam angle that looks fantastic in fittings where the lamp is exposed. These retrofit lamps are highly efficient and are an ideal replacement for traditional tungsten filament bulbs.
- Product Feature 1:
- Filament technology with super-wide beam angle
- Product Feature 2:
- Warm Light
- Product Feature 3:
- 806 Lumens
- Product Feature 4:
- Non-Dimmable
- Availability:
-
0
Call us on 0208 451 8700 to check the next availability
Details
| Barcode | 5055788251446 |
|---|---|
| Quick Order Code | 611881 |
| Category | Lamps |
| Range Name | Classic |
| Product Type | GLS |
| Market Segment | Commercial indoor, Residential indoor |
| Warranty (Years) | 2 |
Physical Data
| Product Length (mm) | 106 |
|---|---|
| Product Width (mm) | 60 |
| Product Weight (g) | 32 |
| Material | Aluminium, Glass |
| Base Term | Bayonet cap |
| Bulb Base | B22 |
| Construction | Glass shell, Filament strip, Aluminium base |
| Globe Finish | Frosted |
| Globe Type | GLS |
| Bulb Fixing | Pendant, Wall, lamp stand, table lamp |
| Bulb or Luminaire Shape | Round |
| Placement / Application | Indoor, General Lighting |
Light Data
| Energy Efficiency Label (Image) | ILGLSB22NF091_EU_label |
|---|---|
| Luminous Flux in Lumens (lm) | 806 |
| Luminous efficacy (lm/W) | 136 |
| Correlated Colour Temperature (CCT) (K) | 5000 |
| Colour Temperature | 5000K - Daylight |
| Colour Temperature Name | Daylight |
| Beam Angle | 330 |
| Colour Rendering Index (CRI) | 80 |
| Frequency Range (Hz) | 50/60 |
| Instant on (Less than 1 second) | Yes |
| LED Type | Filament chip |
| Lifetime (hours) | 15000 |
| Switching Cycles | 50000 |
Electrical Data
| Power (W) | 5.9 |
|---|---|
| Power Consumption (W) | 5.9 |
| Power Factor | 0.5 |
| Voltage Range (v) | 220-240 |
| Wattage equivalent (W) | 60 |
| Amperage (mA) | 36 |
| Dimming | Non-Dimmable |
| Driver Included | Yes |
| Electric Current | AC |
| EN | EN-62560 |
| LVD Certified | Yes |
Environmental
| EN | EN-62560 |
|---|---|
| LVD Certified | Yes |
| CE RoHS | Yes |
| Previous Energy Rating | A+ |
| New Energy Rating | D |
| Hg 0% (Mercury Free) | Yes |
| IP Rating (Ingress Protection) | IP20 |
| Lowest Operating Temperature (°C) | -20 |
| Maximum Operating Temperature (°C) | 40 |
Packaging
| Barcode | 5055788251446 |
|---|---|
| Single box qty | 1 |
| Package Weight (g) | 38, 60 |
| Package Length (mm) | 120 |
| Package Width (mm) | 65 |
| Package Depth (mm) | 65 |
| Inner Carton Barcode | 05055788251453 |
| Qty per Inner Carton | 10 |
| Inner Carton Length (mm) | 340 |
| Inner Carton Width (mm) | 140 |
| Inner Carton Depth (mm) | 130 |
| Outer Carton Barcode | 05055788251460 |
| Qty per Outer Carton | 40 |
| Outer Carton Length (mm) | 358 |
| Outer Carton Width (mm) | 305 |
| Outer Carton Depth (mm) | 290 |
| Qty per euro pallet | 1440 |
