GLASS GU10 BULB 400LM 3.6W 6500K DIMMABLE 36 BEAM INTEGRAL
Part Number:
ILGU10DG088
THIS ITEM IS NOW DISCONTINUED. REPLACEMENT PRODUCT
The glass body and cleverly engineered surface mounted LEDs of the Integral LED Glass GU10 range give them an attractive look that is very similar to traditional halogen lamps.
These GU10 lamps will retrofit easily into existing fittings and provide significant energy savings and longer lifetime than the halogen lamps they are designed to replace.
The glass body and cleverly engineered surface mounted LEDs of the Integral LED Glass GU10 range give them an attractive look that is very similar to traditional halogen lamps.
These GU10 lamps will retrofit easily into existing fittings and provide significant energy savings and longer lifetime than the halogen lamps they are designed to replace.
- Product Feature 1:
- Cool Daylight light
- Product Feature 2:
- 345 Useful Lumens (400 Nominal)
- Product Feature 3:
- Dimmable
- Availability:
-
960
Call us on 0208 451 8700 to check the next availability
Details
| Barcode | 5055788230069 |
|---|---|
| Quick Order Code | 303433 |
| Category | Lamps |
| Range Name | Glass |
| Product Type | GU10 |
| Market Segment | Commercial indoor, Residential indoor |
| Warranty (Years) | 2 |
Physical Data
| Product Length (mm) | 54 |
|---|---|
| Product Width (mm) | 50 |
| Product Weight (g) | 41 |
| Optic | Designed to give a Halogen look |
| Material | Glass |
| Base Term | GU10 |
| Bulb Base | GU10 |
| Construction | Glass body and "fly eye" diffuser lens |
| Globe Finish | Dichroic look |
| Bulb Fixing | Downlight |
| Bulb or Luminaire Shape | Round |
| Placement / Application | Indoor, General Lighting |
| Spot Type | SMD with "COB like effect" |
Light Data
| Energy Efficiency Label (Image) | ILGU10DG088_EU_label |
|---|---|
| Luminous Flux in Lumens (lm) | 400 |
| Luminous efficacy (lm/W) | 112 |
| Peak Intensity (Cd) | 700 |
| Correlated Colour Temperature (CCT) (K) | 6500 |
| Colour Temperature | 6500 - Cool Daylight |
| Colour Temperature Name | Cool Daylight |
| Beam Angle | 36 |
| Colour Rendering Index (CRI) | 80 |
| Compatible Dimmers | Varilight JQP401W |
| Frequency Range (Hz) | 50/60 |
| Instant on (Less than 1 second) | Yes |
| LED Type | Surface mounted device (SMD) |
| Lifetime (hours) | 15000 |
| Switching Cycles | 50000 |
| Useful Lumens (lm) | 345 |
Electrical Data
| Power (W) | 3.6 |
|---|---|
| Power Consumption (W) | 3.6 |
| Power Factor | 0.4 |
| Voltage Range (v) | 220-240 |
| Wattage equivalent (W) | 50 |
| Amperage (mA) | 21 |
| Dimming | Mains dim |
| Driver Included | Yes |
| Electric Current | AC |
| EN | EN-62560 |
| LVD Certified | Yes |
Environmental
| EN | EN-62560 |
|---|---|
| LVD Certified | Yes |
| CE RoHS | Yes |
| New Energy Rating | E |
| Hg 0% (Mercury Free) | Yes |
| IP Rating (Ingress Protection) | IP20 |
| Lowest Operating Temperature (°C) | -20 |
| Maximum Operating Temperature (°C) | 40 |
Packaging
| Barcode | 5055788230069 |
|---|---|
| Single box qty | 1 |
| Package Weight (g) | 53 |
| Package Length (mm) | 55 |
| Package Width (mm) | 55 |
| Package Depth (mm) | 60 |
| Outer Carton Barcode | 05055788230083 |
| Qty per Outer Carton | 100 |
| Outer Carton Length (mm) | 595 |
| Outer Carton Width (mm) | 307 |
| Outer Carton Depth (mm) | 165 |
| Qty per euro pallet | 4400 |
