TOUGHSHELL WEATHERPROOF BATTEN IP65 IK10 75W 4000k 9000lm 120° BEAM 6ft 3hr EMERGENCY

Part Number:

ILBTD111

The Tough-Shell Batten features a tough IK08 and IP65 dust and waterproof polycarbonate casing with secure clips. The frosted diffuser provides even light distribution. Ideal for demanding environments such as warehouses, factories, car parks and more.

This model features an integrated Emergency Function to provide three hours of illumination in the event of a power cut.

Product Feature 1:
Integrated Emergency Function
Product Feature 2:
IK08 for high impact resistance
Product Feature 3:
IP65 body protects against dust and moisture ingress
Product Feature 4:
Long 50000 hour lifetime
Product Feature 5:
Highly efficient - 120lm/W
Product Feature 6:
3 year warranty
Availability:
100+

Call us on 0208 451 8700 to check the next availability

Quick Order Code 916772
Barcode 5055788253891
Category Luminaires
Range Name Tough-Shell
Product Body Finish Matt white
Market Segment Indoor commercial, Industrial, residential
Finish Matt White
Warranty (Years) 3
Product Length (mm) 1850
Product Depth (mm) 83
Product Width (mm) 123
Optic Opal diffuser
Material Polycarbonate
Construction Polycarbonate casing and diffuser
Bulb or Luminaire Shape Rectangle
Luminaire Fixing Wall/Ceiling mounted
Placement / Application Indoor, General Lighting
Energy Efficiency Label (Image) ILBTD111_EU_label
Luminous Flux in Lumens (lm) 9000
Luminous efficacy (lm/W) 120
Correlated Colour Temperature (CCT) (K) 4000
Colour Temperature 4000K - Cool White
Colour Temperature Name Cool White
Beam Angle 120
Colour Rendering Index (CRI) 80
Frequency Range (Hz) 50/60
Instant on (Less than 1 second) Yes
LED Size (mm) 2835
LED Type Surface mounted device (SMD)
Lifetime (hours) 50000
Switching Cycles 50000
Useful Lumens (lm) 400
Power (W) 75
Power Consumption (W) 75
Power Factor 0.9
Voltage Range (v) 200-240
Dimming Non-Dimmable
Driver Included Yes
Electric Current AC
LVD Certified Yes
LVD Certified Yes
CE RoHS Yes
New Energy Rating E
Hg 0% (Mercury Free) Yes
IK Rating (Impact Protection) IK08
IP Rating (Ingress Protection) IP65
Lowest Operating Temperature (°C) -20
Maximum Operating Temperature (°C) 40
