CONSTANT CURRENT DRIVER 10.5W 250MA IP20 NON-DIMMABLE 32-42V OUTPUT INTEGRAL
Part Number:
ILDRCCA072A
10.5W TRIAC dimmable constant current LED driver.
Integral LED Constant Current Drivers are designed and built using highly reliable components to deliver the best performance for commercial and residential lighting applications.
- Product Feature 1:
- Input Voltage: 220-240VAC
- Product Feature 2:
- Output: 10.5W
- Product Feature 3:
- 250mA
- Product Feature 4:
- Constant current
- Product Feature 5:
- Class II
- Availability:
-
100+
Call us on 0208 451 8700 to check the next availability
Suggested products
Details
| Quick Order Code | 931963 |
|---|---|
| Barcode | 5055788268451 |
| Category | Drivers |
| Range Name | TRIAC |
| Product Type | Constant Current |
| Market Segment | Commercial indoor, Residential indoor |
| Warranty (Years) | 3 |
Physical Data
| Product Length (mm) | 100 |
|---|---|
| Product Depth (mm) | 20 |
| Product Width (mm) | 40 |
| Product Weight (g) | 42 |
| Placement / Application | Indoor, General Lighting |
Light Data
| Frequency Range (Hz) | 50/60 |
|---|
Electrical Data
| Power Consumption (W) | 10.5 |
|---|---|
| Power Factor | 0.55 |
| Voltage (V) | 32-42 |
| Voltage Range (v) | 220-240 |
| Input Current (A) | 0.125 |
| Input Voltage (V) | 220-240VAC |
| Output Current (mA) | 250 |
| Dimming | Non-Dimmable |
| Electric Current | AC |
| Protection Function | Short Circuit Protection, Overload Protection, Overheat Protection |
| EN | EN-60598 |
| LVD Certified | Yes |
Environmental
| EN | EN-60598 |
|---|---|
| LVD Certified | Yes |
| CE RoHS | Yes |
| Hg 0% (Mercury Free) | Yes |
| IP Rating (Ingress Protection) | IP20 |
| Lowest Operating Temperature (°C) | -25 |
| Maximum Operating Temperature (°C) | 85 |
