LUXFIRE FIRE RATED DOWNLIGHT 70MM CUTOUT IP65 450LM 6W 4000K 36 BEAM DIMMABLE 75LM/W WHITE INTEGRAL
Part Number:
ILDLFR70A002
Who says you can't have style without safety? Integral LED Lux Fire downlights not only conform to 30, 60 and 90mins fire rating specifications but are also rated to IP65, so they can be used safely in bathrooms. Lux Fire fire-rated downlights have been tailored to deliver a premium finish to any home or business with their low-glare, high-quality light and contemporary design that looks impressive in any setting. Lux Fire downlights are built using a deep recessed COB LED light source, providing a beam that has softened edges for a luxurious effect. Supplied with a white scalloped metal bezel (interchangeable). Easy to install with low-profile body. Complete with Loop-in / Loop-out driver. IP65 and Air tightness compliant with Part C and Part L. Resistance to Sound compliant with Part E.
Note: Warranty increased to 5 years on 27/03/2025
- Product Feature 1:
- Cool White
- Product Feature 2:
- 450 Lumens
- Product Feature 3:
- Dimmable
- Product Feature 4:
- Matt white finish
- Product Feature 5:
- Awarded 4 Stars Recommended by Lux Review
For this product to qualify as an Emergency product, it requires an Emergency Conversion Kit that can be purchased separately.
Please see Suggested products below for more information
- Availability:
-
460
Call us on 0208 451 8700 to check the next availability
Suggested products
Details
| Barcode | 5055788213727 |
|---|---|
| Quick Order Code | 808270 |
| Product Type | Fire Rated |
| Category | Downlights |
| Range Name | Lux Fire |
| Fixed/Tiltable | Fixed |
| Finish | Matt White |
| Product Body Finish | Matt white |
| Market Segment | Commercial indoor, Residential indoor |
| Placement / Application | Indoor, General Lighting |
| Warranty (Years) | 5 |
Physical Data
| Cut Out Diameter (mm) | 70 |
|---|---|
| Diameter (mm) | 85 |
| Overall diameter (mm) | 85 |
| Product Length (mm) | 70 |
| Product Weight (g) | 370 |
| Material | Aluminium alloy, Acrylic, Iron |
| Construction | Extruded Aluminium alloy heat-sink, Iron body, Steel springs and mounting plate, Acrylic diffuser |
| Luminaire Fixing | Recess mounted |
| Emergency Option | Optional Conversion Kit |
| Emergency Category | Downlights |
| Optic | Clear Refractor |
| Spot Type | COB |
Light Data
| Luminous Flux in Lumens (lm) | 450 |
|---|---|
| Luminous efficacy (lm/W) | 75 |
| Correlated Colour Temperature (CCT) (K) | 4000 |
| Colour Temperature | 4000 - Cool White |
| Colour Temperature Name | Cool White |
| Beam Angle | 36 |
| Colour Rendering Index (CRI) | 80 |
| Compatible Dimmers | Varilight JQP401W |
| Frequency Range (Hz) | 50/60 |
| Instant on (Less than 1 second) | Yes |
| LED Type | Chip on board (COB) |
| Lifetime (hours) | 35000 |
| Switching Cycles | 17500 |
| Light Source | Non-replaceable |
Electrical Data
| Power (W) | 6 |
|---|---|
| Power Consumption (W) | 6 |
| Power Factor | 0.89 |
| Voltage Range (v) | 220-240 |
| Wattage equivalent (W) | 38 |
| Amperage (mA) | 500 |
| Dimming | Mains dim |
| Driver Included | Yes |
| Electric Current | AC |
Environmental
| Fire Rating (mins) | 30, 60, 90 |
|---|---|
| IP Rating (Ingress Protection) | IP65 |
| Lowest Operating Temperature (°C) | -20 |
| Maximum Operating Temperature (°C) | 45 |
| EN | EN-60598 |
| LVD Certified | Yes |
| CE RoHS | Yes |
| Hg 0% (Mercury Free) | Yes |
| New Energy Rating | F |
| EU Luminaire | L |
Packaging
| Single box qty | 1 |
|---|---|
| Barcode | 5055788213727 |
| Package Weight (g) | 410 |
| Package Length (mm) | 140 |
| Package Width (mm) | 110 |
| Package Depth (mm) | 95 |
| Inner Carton Barcode | 05055788214021 |
| Qty per Inner Carton | 10 |
| Inner Carton Length (mm) | 550 |
| Inner Carton Width (mm) | 200 |
| Inner Carton Depth (mm) | 95 |
| Qty per Outer Carton | 36 |
| Outer Carton Length (mm) | 460 |
| Outer Carton Width (mm) | 320 |
| Outer Carton Depth (mm) | 310 |
