COMPACT TOUGH FLOODLIGHT WITH PIR OVERRIDE IP64 2700LM 30W 3000K 110B NON-DIMM 90LM/W WHITE INTEGRAL
Part Number:
ILFLC131POV
THIS ITEM IS NOW UPGRADED OR DISCONTINUED. CONTACT US TO FIND A REPLACEMENT PRODUCT.
The new generation of Compact-Tough Floodlights are lighter and even more compact, with a frosted lens for reduced glare.
The Compact-Tough IP65-rated LED Floodlight breaks from convention with a design that meets the desire for attractive exterior lights. Meanwhile, a tough aluminium body and tempered glass refractor ensure that these floodlights are built to last. With 85% lower running costs compared to halogen equivalents, the Compact-Tough not only looks great, it is incredibly efficient as well.
For added convenience and functionality the Compact-Tough Floodlight is also available with a PIR sensor, so you get bright, energy-efficient light when and where you need it. Many exterior lights with PIR sensors have sensors with IP ratings far below that of the luminaire itself. This means that while the luminaire will be tough and last for a long time, the sensor may be fragile and not last as long. The PIR sensor on the Integral LED Compact-Tough is rated at IP64 which means it has good weather-proof properties (resistant to water spray from any direction, as well as ingress of dust). This model also features a PIR Override feature, which allows you to set an "always on" mode for times when you want the light to remain on and not rely on the PIR sensor.
- Product Feature 1:
- Tough aluminium and polycarbonate body with marine grade fixings
- Product Feature 2:
- Frosted tempered glass lens for reduced glare
- Product Feature 3:
- Highly reliable IP64 PIR Sensor (many LED floodlight sensors are only IP44)
- Product Feature 4:
- More efficient (up to 90lm/W)
- Product Feature 5:
- 85% lower running cost (compared to Halogen)than other LED floodlights on the market
- Product Feature 6:
- Pre-wired 2m cable for easy installation
- Product Feature 7:
- Maintenance-free and no lamp to change
- Availability:
-
0
Call us on 0208 451 8700 to check the next availability
Suggested products
Details
Quick Order Code | 638250 |
---|---|
Barcode | 5055788246879 |
Category | Luminaires |
Range Name | Compact Tough |
Product Type | Floodlights |
Product Body Finish | Matt white |
Market Segment | Commercial and Residential outdoor |
Finish | Matt White |
Features | PIR Sensor with override |
Warranty (Years) | 2 |
Physical Data
Emergency Option | No |
---|---|
PIR | Yes with Overide Function |
Linkable | No |
Product Length (mm) | 150 |
Product Depth (mm) | 76 |
Product Width (mm) | 176 |
Product Weight (g) | 628 |
Optic | Polycarbonate diffuser |
Material | Aluminium, Polycarbonate, Tempered glass |
Construction | Aluminium and polycarbonate body, Tempered glass, Integrated driver |
Bulb or Luminaire Shape | Rectangle |
Luminaire Fixing | Wall |
Mounting Type | Rear Cable Entry |
Panel Equivalent | 200 |
Placement / Application | Outdoor, General Lighting |
Light Data
Beam Type | Symmetrical |
---|---|
Energy Efficiency Label (Image) | ILFLC131POV_EU_label |
Luminous Flux in Lumens (lm) | 2700 |
Luminous efficacy (lm/W) | 90 |
Correlated Colour Temperature (CCT) (K) | 3000 |
Colour Temperature Name | Warm White |
Beam Angle | 110 |
Colour Rendering Index (CRI) | 80 |
Frequency Range (Hz) | 50/60 |
Instant on (Less than 1 second) | Yes |
LED Type | Surface mounted device (SMD) |
Lifetime (hours) | 35000 |
Sensor / Overide | Yes with Override |
Switching Cycles | 17500 |
Useful Lumens (lm) | 2700 |
Electrical Data
Power Consumption (W) | 30 |
---|---|
Power Factor | 0.9 |
Voltage Range (v) | 220-240 |
Amperage (mA) | 200 |
Input Voltage (V) | 220-240 |
Dimming | Non-Dimmable |
Driver Included | Yes |
Electric Current | AC |
EN | EN-60598 |
LVD Certified | Yes |
Environmental
EN | EN-60598 |
---|---|
LVD Certified | Yes |
CE RoHS | Yes |
EU Luminaire | L |
Hg 0% (Mercury Free) | Yes |
IK Rating (Impact Protection) | IK08 |
IP Rating (Ingress Protection) | IP64 |
Lowest Operating Temperature (°C) | -25 |
Maximum Operating Temperature (°C) | 45 |
Packaging
Package Weight (g) | 792 |
---|---|
Package Length (mm) | 157 |
Package Width (mm) | 60 |
Package Depth (mm) | 130 |
