The new generation of Compact-Tough Floodlights are lighter and even more compact, with a frosted lens for reduced glare.

The Compact-Tough IP65-rated LED Floodlight breaks from convention with a design that meets the desire for attractive exterior lights. Meanwhile, a tough aluminium body and tempered glass refractor ensure that these floodlights are built to last. With 85% lower running costs compared to halogen equivalents, the Compact-Tough not only looks great, it is incredibly efficient as well.

For added convenience and functionality the Compact-Tough Floodlight is also available with a PIR sensor, so you get bright, energy-efficient light when and where you need it. Many exterior lights with PIR sensors have sensors with IP ratings far below that of the luminaire itself. This means that while the luminaire will be tough and last for a long time, the sensor may be fragile and not last as long. The PIR sensor on the Integral LED Compact-Tough is rated at IP64 which means it has good weather-proof properties (resistant to water spray from any direction, as well as ingress of dust). This model also features a PIR Override feature, which allows you to set an "always on" mode for times when you want the light to remain on and not rely on the PIR sensor.

Product Feature 1:
Tough aluminium and polycarbonate body with marine grade fixings
Product Feature 2:
Frosted tempered glass lens for reduced glare
Product Feature 3:
Highly reliable IP64 PIR Sensor (many LED floodlight sensors are only IP44)
Product Feature 4:
More efficient (up to 90lm/W)
Product Feature 5:
85% lower running cost (compared to Halogen)than other LED floodlights on the market
Product Feature 6:
Pre-wired 2m cable for easy installation
Product Feature 7:
Maintenance-free and no lamp to change

Call us on 0208 451 8700 to check the next availability

Suggested products

Quick Order Code 656511
Barcode 5055788246886
Category Luminaires
Range Name Compact Tough
Product Type Floodlights
Product Body Finish Matt white
Market Segment Commercial and Residential outdoor
Finish Matt White
Features PIR Sensor with override
Warranty (Years) 2
Emergency Option No
PIR Yes with Overide Function
Linkable No
Product Length (mm) 188
Product Depth (mm) 80
Product Width (mm) 201
Product Weight (g) 1003
Optic Polycarbonate diffuser
Material Aluminium, Polycarbonate, Tempered glass
Construction Aluminium and polycarbonate body, Tempered glass, Integrated driver
Bulb or Luminaire Shape Rectangle
Luminaire Fixing Wall
Mounting Type Rear Cable Entry
Panel Equivalent 400
Placement / Application Outdoor, General Lighting
Beam Type Symmetrical
Energy Efficiency Label (Image) ILFLC132POV_EU_label
Luminous Flux in Lumens (lm) 4500
Luminous efficacy (lm/W) 90
Correlated Colour Temperature (CCT) (K) 3000
Colour Temperature Name Warm White
Beam Angle 110
Colour Rendering Index (CRI) 80
Frequency Range (Hz) 50/60
Instant on (Less than 1 second) Yes
LED Type Surface mounted device (SMD)
Lifetime (hours) 35000
Sensor / Overide Yes with Override
Switching Cycles 17500
Useful Lumens (lm) 4500
Power Consumption (W) 50
Power Factor 0.9
Amperage (mA) 400
Input Voltage (V) 220-240
Dimming Non-Dimmable
Driver Included Yes
Electric Current AC
EN EN-60598
LVD Certified Yes
EN EN-60598
LVD Certified Yes
EU Luminaire L
Hg 0% (Mercury Free) Yes
IK Rating (Impact Protection) IK08
IP Rating (Ingress Protection) IP64
Lowest Operating Temperature (°C) -25
Maximum Operating Temperature (°C) 45
Package Weight (g) 1192
Package Length (mm) 195
Package Width (mm) 60
Package Depth (mm) 155
