CONSTANT VOLTAGE DRIVER 320W 24VDC IP65 NON-DIMM 90-305V INPUT MEANWELL

Part Number:

HLG-320H-24A

This non-dimmable 320W constant voltage LED driver operates 115-277VAC input range. The LED driver provides 24V constant voltage for applications such as 24V LED strip lighting.

Product Feature 1:
Input Voltage: 115-277VAC
Product Feature 2:
Output Power: 320W
Product Feature 3:
Output: 24VDC Constant Voltage
Product Feature 4:
Short Circuit / Over Load / Over Heat Protection
Availability:
18

Call us on 0208 451 8700 to check the next availability

Quick Order Code 166747
Barcode 5055788229155
Category Drivers
Range Name Non-Dimmable
Product Type Constant Voltage
Market Segment Commercial indoor, Residential indoor, Commercial outdoor, Residential outdoor
Warranty (Years) 5
Product Length (mm) 252
Product Depth (mm) 44
Product Width (mm) 90
Product Weight (g) 1795
Placement / Application Indoor LED Lighting, Outdoor LED Light
Frequency Range (Hz) 50/60
Power (W) 320
Power Consumption (W) 320
Power Factor 0.9
Voltage (V) 24
Input Voltage (V) 115-277
Output Current (mA) 13340
Dimming Non-Dimmable
Protection Function Short Circuit Protection, Overload Protection, Overheat Protection
EN EN61347-1, EN61347-2-13, EN55015, EN6100-3-3, EN6100-3-2, EN61547
LVD Certified Yes
EN EN61347-1, EN61347-2-13, EN55015, EN6100-3-3, EN6100-3-2, EN61547
LVD Certified Yes
CE RoHS Yes
Hg 0% (Mercury Free) Yes
IP Rating (Back/Recessed side) IP20
IP Rating (Ingress Protection) IP65
Lowest Operating Temperature (°C) -20
Maximum Operating Temperature (°C) 45
Package Weight (g) 1935
Package Length (mm) 335
Package Width (mm) 125
Package Depth (mm) 60

Product Specification Sheet

Safety Guides
