STRIP IP20 5M RGB 24V 4.8W/M 30LED/M 12MM WIDTH 115 BEAM BAG PACK INTEGRAL

Part Number:

ILSTRGBA119E

This 5M RGB LED strip is offers attractive, colour changing lighting with consistant light and colour across the whole strip.

This strip is compatible with our RGB 20M pack (ILSTRGBA115E).

Product Feature 1:
RGB Colour Changing
Product Feature 2:
Can run up to 20 metres from one driver
Product Feature 3:
24V DC Constant Voltage
Product Feature 4:
30 LEDs per metre
Product Feature 5:
4.8W per metre
Product Feature 6:
LED size 50:50
Availability:
100+

More stock due in on 25/11/2024

Suggested products

Quick Order Code 798289
Barcode 5055788243229
Category Strips
Range Name RGB Strip
Product Type Colour strip
Market Segment Commercial indoor, Residential indoor
Features RGB
Warranty (Years) 3
Product Width (mm) 12
Product Weight (g) 100
Material PCB
Construction LED surface mounted on to strip
Strip Cut Points (mm) 166
Max Run Length (m) 20
Placement / Application Decorative indoor
Strip length (M) 5
Strip Width (mm) 12
Colour Temperature Name RGB
Beam Angle 115
Colour Type RGB
LED Size (mm) 5050
LED Type Surface mounted device (SMD)
LEDs per meter 30
Lifetime (hours) 25000
Power Consumption per meter (W/m) 4.8
Voltage (V) 24
Voltage Range (v) 24
Watts per metre 3.1W - 6w
Dimming Dimmable
Driver Included No
Electric Current DC
EN IEC 62031
LVD Certified Yes
EN IEC 62031
LVD Certified Yes
CE RoHS Yes
Hg 0% (Mercury Free) Yes
IP Rating (Ingress Protection) IP20
Lowest Operating Temperature (°C) -25
Maximum Operating Temperature (°C) 60
Package Weight (g) 120
Package Length (mm) 240
Package Width (mm) 210
Package Depth (mm) 12
