OUTDOOR WALL PACK ADJUSTABLE IP65 9840LM 80W 4000K 120 BEAM BLACK INTEGRAL

Part Number:

ILWPC005

Integral Compact Tough Wall Pack Lights are ideal for perimeter lighting as well as pedestrian and vehicle access areas in commercial and industrial environments. The IP65 weatherproof and IK08 impact-resistant cast aluminium body makes it perfectly suitable for outdoor installation.

This model features a 90 degree adjustable head to shine light where you want it.

Product Feature 1:
0-90 degree adjustable head
Product Feature 2:
Stylish and contemporary design
Product Feature 3:
Hard-wearing and weatherproof
Product Feature 4:
Cast-aluminium body
Availability:
100+

Call us on 0208 451 8700 to check the next availability

Suggested products

Quick Order Code 845465
Barcode 5055788243205
Category Luminaires
Range Name Compact Tough
Product Type Wall Packs
Product Body Finish Dark Brown
Market Segment Outdoor
Finish Dark Brown
Warranty (Years) 3
Emergency Option No
Linkable No
Product Length (mm) 285
Product Depth (mm) 119
Product Width (mm) 265
Product Weight (g) 4290
Optic Polycarbonate diffuser
Material ADC12 Aluminium
Construction Aluminium heat-sink, PC injection moulded driver case
Bulb or Luminaire Shape Rectangle
Luminaire Fixing Wall
Mounting Type Rear Cable Entry
Placement / Application Outdoor
Energy Efficiency Label (Image) ILWPC005_EU_label
Luminous Flux in Lumens (lm) 9840
Luminous efficacy (lm/W) 123
Correlated Colour Temperature (CCT) (K) 4000
Colour Temperature Name Cool White
Beam Angle 116
Colour Rendering Index (CRI) 80
Frequency Range (Hz) 50/60
Lifetime (hours) 50000
Switching Cycles 100000
Useful Lumens (lm) 9840
Power Consumption (W) 80
Power Factor 0.95
Voltage Range (v) 100-277
Input Voltage (V) 220-240
Dimming Non-Dimmable
Electric Current AC
EN EN-60598
LVD Certified Yes
EN EN-60598
LVD Certified Yes
CE RoHS Yes
EU Luminaire L
Hg 0% (Mercury Free) Yes
IK Rating (Impact Protection) IK08
IP Rating (Ingress Protection) IP65
Lowest Operating Temperature (°C) 0
Maximum Operating Temperature (°C) 45
Package Weight (g) 4690
Package Length (mm) 335
Package Width (mm) 315
Package Depth (mm) 170
