SLIM WALLPACK LIGHT SENSOR 20/30W 2400/3600LM CCT SWITCHABLE 3/4/6K 110 BEAM IP65 IK10 120LM/W NON-DIMM INTEGRAL
Part Number:
ILWPF002
With a compact and minimal design, the Integral LED Slim Wallpack is ideal for industrial environments, like car parks, logistics centres and warehouses.
The luminaire features a polycarbonate body that provides IK10 and IP65 protection, making it robust enough for the most demanding installations. Suitable for both indoor and outdoor settings, it offers switchable CCT options of 3000K, 4000K, and 6000K, as well as adjustable power settings to meet various application requirements.
Equipped with a photocell sensor, this Wallpack turns on at dusk and off at dawn to provide automatic illumination during nighttime hours.
- Product Feature 1:
- Compact and Clean design
- Product Feature 2:
- Hard-wearing and weatherproof
- Product Feature 3:
- CCT Switchable 3000K-4000K-6000K
- Product Feature 4:
- Auto light sensor disables light in dark conditions, saving battery
- Availability:
-
100+
Call us on 0208 451 8700 to check the next availability
Suggested products
Details
| Quick Order Code | 975183 |
|---|---|
| Barcode | 5055788298656 |
| Category | Luminaires |
| Range Name | Slim Wallpack |
| Product Type | Wall Packs |
| Product Body Finish | Black |
| Market Segment | Outdoor |
| Finish | Black |
| Warranty (Years) | 5 |
Physical Data
| Emergency Option | No |
|---|---|
| Product Length (mm) | 306 |
| Product Depth (mm) | 265 |
| Product Width (mm) | 115 |
| Product Weight (g) | 1020 |
| Optic | Polycarbonate diffuser |
| Material | ADC12 Aluminium |
| Construction | Polycarbonate |
| Bulb or Luminaire Shape | Rectangle |
| Luminaire Fixing | Wall |
| Mounting Type | Rear Cable Entry |
| Placement / Application | Outdoor |
Light Data
| Luminous Flux in Lumens (lm) | 1900/2700 |
|---|---|
| Luminous efficacy (lm/W) | 95 |
| Correlated Colour Temperature (CCT) (K) | 3000/4000/6000 |
| Colour Temperature Name | Warm White - Cool White - Daylight |
| Beam Angle | 110 |
| Colour Rendering Index (CRI) | 80 |
| Frequency Range (Hz) | 50/60 |
| Lifetime (hours) | 50000 |
| Switching Cycles | 25000 |
| Useful Lumens (lm) | 1900/2700 |
Electrical Data
| Power Consumption (W) | 20/30 |
|---|---|
| Power Factor | 0.9 |
| Voltage Range (v) | 100-277 |
| Input Voltage (V) | 220-240 |
| Dimming | Non-Dimmable |
| Electric Current | AC |
| EN | EN-60598 |
| LVD Certified | Yes |
Environmental
| EN | EN-60598 |
|---|---|
| LVD Certified | Yes |
| CE RoHS | Yes |
| EU Luminaire | L |
| Hg 0% (Mercury Free) | Yes |
| IK Rating (Impact Protection) | IK10 |
| IP Rating (Ingress Protection) | IP65 |
| Lowest Operating Temperature (°C) | -20 |
| Maximum Operating Temperature (°C) | 45 |
Packaging
| Package Weight (g) | 1240 |
|---|---|
| Package Length (mm) | 31 |
| Package Width (mm) | 27 |
| Package Depth (mm) | 11.5 |
Safety Guide
ILWPF001-005-20W3000K
