SLIM WALLPACK EMERGENCY 20/30W 2400/3600LM CCT SWITCHABLE 3/4/6K 110 BEAM IP65 IK10 120LM/W NON-DIMM INTEGRAL
Part Number:
ILWPF004
With a compact and minimal design, the Integral LED Slim Wallpack is ideal for industrial environments, like car parks, logistics centres and warehouses.
The luminaire is equipped with a polycarbonate body that provides IK10 and IP65 protection, making it robust enough for the most demanding installations. Suitable for both indoor and outdoor settings, it offers switchable CCT options of 3000K, 4000K, and 6000K, as well as adjustable power settings to meet various application requirements.
Equipped for emergency lighting, ensuring 3 hours of illumination during a crisis situation or power outage.
- Product Feature 1:
- Compact and Clean design
- Product Feature 2:
- Hard-wearing and weatherproof
- Product Feature 3:
- CCT Switchable 3000K-4000K-6000K
- Product Feature 4:
- 3 Hour Emergency Illumination
- Availability:
-
64
More stock due in on 14/12/2024
Suggested products
Details
Quick Order Code | 803347 |
---|---|
Barcode | 5055788298670 |
Category | Luminaires |
Range Name | Slim Wallpack |
Product Type | Wall Packs |
Product Body Finish | Black |
Market Segment | Outdoor |
Finish | Black |
Warranty (Years) | 5 |
Physical Data
Emergency Option | Yes |
---|---|
Product Length (mm) | 306 |
Product Depth (mm) | 265 |
Product Width (mm) | 115 |
Product Weight (g) | 1200 |
Optic | Polycarbonate diffuser |
Material | ADC12 Aluminium |
Construction | Polycarbonate |
Bulb or Luminaire Shape | Rectangle |
Luminaire Fixing | Wall |
Mounting Type | Rear Cable Entry |
Placement / Application | Outdoor |
Light Data
Luminous Flux in Lumens (lm) | 1900/2700 |
---|---|
Luminous efficacy (lm/W) | 95 |
Correlated Colour Temperature (CCT) (K) | 3000/4000/6000 |
Colour Temperature Name | Warm White - Cool White - Daylight |
Beam Angle | 110 |
Colour Rendering Index (CRI) | 80 |
Frequency Range (Hz) | 50/60 |
Lifetime (hours) | 50000 |
Switching Cycles | 25000 |
Useful Lumens (lm) | 1900/2700 |
Electrical Data
Power Consumption (W) | 20/30 |
---|---|
Power Factor | 0.9 |
Voltage Range (v) | 100-277 |
Input Voltage (V) | 220-240 |
Dimming | Non-Dimmable |
Electric Current | AC |
EN | EN-60598 |
LVD Certified | Yes |
Environmental
EN | EN-60598 |
---|---|
LVD Certified | Yes |
CE RoHS | Yes |
EU Luminaire | L |
Hg 0% (Mercury Free) | Yes |
IK Rating (Impact Protection) | IK10 |
IP Rating (Ingress Protection) | IP65 |
Lowest Operating Temperature (°C) | -20 |
Maximum Operating Temperature (°C) | 45 |
Packaging
Package Weight (g) | 1420 |
---|---|
Package Length (mm) | 31 |
Package Width (mm) | 27 |
Package Depth (mm) | 11.5 |
