PRECISE FLOOD 150W 15000LM 4000K 90 BEAM 100LM/W IP65 IK08 INTEGRAL LED BLACK
Part Number:
ILFLF005
Built to withstand the harshest conditions, the Integral LED Precision Plus 2 Floodlight features a die-cast aluminium body and polycarbonate lens with IP65 ingress protection and IK08 impact resistance, ensuring exceptional durability in any environment.
Engineered for efficiency, the Precision Plus 2 delivers up to 160lm/W efficacy, providing powerful illumination while minimising energy consumption.
With a pre-wired 1m rubberised flex for enhanced installation speed, upgrading your outdoor lighting has never been simpler.
- Product Feature 1:
- 160lm/W
- Product Feature 2:
- IP65 body protects against dust and moisture ingress
- Product Feature 3:
- IK08
- Product Feature 4:
- 5 year warranty
- Availability:
-
100+
More stock due in on 01/05/2025
Suggested products
Details
| Quick Order Code | 807341 |
|---|---|
| Barcode | 5055788293095 |
| Category | Luminaires |
| Range Name | Precision Plus 2 |
| Product Type | Floodlights |
| Product Body Finish | Black |
| Market Segment | Commercial & Industrial Outdoor |
| Finish | Black |
| Warranty (Years) | 5 |
Physical Data
| Emergency Option | No |
|---|---|
| Product Length (mm) | 328.5 |
| Product Depth (mm) | 44.5 |
| Product Width (mm) | 295 |
| Product Weight (g) | 1650 |
| Optic | Clear Refractor |
| Material | Aluminium, Polycarbonate, Glass |
| Construction | Die cast Aluminium heat-sink and body, Polycarbonate sheet diffuser |
| Bulb or Luminaire Shape | Rectangle |
| Luminaire Fixing | Wall Mounted |
| Mounting Type | Pre Wired 1M flex |
| Placement / Application | Indoor and outdoor, General lighting |
Light Data
| Beam Type | Symmetrical |
|---|---|
| Luminous Flux in Lumens (lm) | 24000 |
| Luminous efficacy (lm/W) | 160 |
| Correlated Colour Temperature (CCT) (K) | 4000 |
| Colour Temperature Name | Cool White |
| Beam Angle | 110 |
| Colour Rendering Index (CRI) | 70 |
| Frequency Range (Hz) | 50 |
| Instant on (Less than 1 second) | Yes |
| LED Type | Surface mounted device (SMD) |
| Lifetime (hours) | 50000 |
| Sensor / Overide | No |
| Switching Cycles | 50000 |
| Useful Lumens (lm) | 24000 |
Electrical Data
| Power Consumption (W) | 150 |
|---|---|
| Power Factor | 0.9 |
| Voltage Range (v) | 100-240 |
| Amperage (mA) | 680 |
| Input Voltage (V) | 100-240 |
| Dimming | Non-Dimmable |
| Driver Included | Yes |
| Electric Current | AC |
| EN | EN-60598 |
| LVD Certified | Yes |
Environmental
| EN | EN-60598 |
|---|---|
| LVD Certified | Yes |
| CE RoHS | Yes |
| EU Luminaire | L |
| Hg 0% (Mercury Free) | Yes |
| IK Rating (Impact Protection) | IK08 |
| IP Rating (Ingress Protection) | IP65 |
| Lowest Operating Temperature (°C) | -20 |
| Maximum Operating Temperature (°C) | 40 |
Packaging
| Package Weight (g) | 2000 |
|---|---|
| Package Length (mm) | 331 |
| Package Width (mm) | 298 |
| Package Depth (mm) | 48 |
Safety Guide
ILFLF005
